Double-wing expandable containers are a versatile, innovative solution for anyone who needs additional living or working space. There are a variety of layouts to choose from, with single bedroom and living room, two bedrooms and living room, and even three bedrooms and living room options available. This flexibility makes it a perfect choice for everyone from small families to large groups.
One of the best features of double-wing expandable containers is that they can be easily folded for fast and efficient transportation. This means that it can be easily moved from one location to another, which is a huge advantage for those who want to relocate their home or office quickly and easily. In addition, the compact and foldable design significantly reduces transportation costs.
Double-wing expandable containers are designed to comply with various standards and specifications, and electrical equipment can be easily installed according to the electrical requirements of different countries. This means that you can use it anywhere in the world without worrying about voltage or current issues.
In terms of design and functionality, double-wing expandable containers stand out in the market. The sophisticated design and modern interior provide a comfortable and convenient environment. Easily customize the interior layout to meet your own requirements.
In conclusion, double-wing expandable containers are a great alternative to traditional housing and office spaces. Its flexibility and innovative design provide a practical solution for residential and office spaces as well as commercial and public spaces such as event venues, clinics, and classrooms. Easy to transport, quick to install, and customizable to your specific needs, it is a cost-effective option for those who need extra space and will continue to revolutionize the way we live and work in the future.
| 20 feet extension house Sheet |
| Project name |
20 feet extension house |
|
| |
Folded size: 5800(L)*2200(W)*2530mm(H) Unfolded size: 5800(L)*6400(W)*2530mm(H) |
The 50th Wall |
| Your request |
3 glass doors are double glazed, 1 glass wall is double glazed, bathroom partition is glass sliding door which needs roof, exterior wall thickness is 50, exterior wall is metal hanging panel, cabinets, water pipes, electrical appliances, Australian standard, 3 exterior doors, 2 interior doors, 1 glass sliding door total, 5 windows of 930 and 1 window of 600. |
| project |
specification |
unit |
amount |
| Roof structure |
Galvanized steel frame 120mm*60mm*2.5/80mm*80mm1.5/20mm*40mm*1.0 (ceiling bracket) 10*20*1.0 (main building) |
set |
1 |
| Bottom Structure |
Galvanized steel frame 120mm*60mm*2.5/80mm*80mm2.0/80mm*40mm2.0 |
set |
1 |
| Folding frame |
Galvanized steel frame 80mm*80mm2.0/80mm*40mm2.0//1.5mm U-shaped closure/L-shaped, Z-shaped water baffle |
set |
1 |
| prism |
Galvanized steel pipe 150*150*3mm/80*80*2.5 |
set |
4 |
| Drooping Head |
210*160*140mm National Standard Special Marine Cast Iron Hanger/Upper 4 sets, lower 4 sets |
set |
8 |
| Wall panels |
50mm thick EPS sandwich cleaning board, 0.4mm thick color steel plate on both sides. Divider board 50mm |
set |
1 |
| Roof Panel |
Sides: 50mm thick EPS sandwich panel, both sides: 0.4mm thick colored steel plate |
㎡ |
29 |
| Inside cover |
06mm container top corrugated steel plate |
㎡ |
29 |
| Bottom plate |
15mm thick cement floor + plywood + PVC floor leather decorative layer |
m³ |
90 |
| Connecting hinge |
Heavy duty steel hinges 15mm, 10mm |
group |
1 |
| Entrance door |
Aluminum alloy heat insulation bridge tempered glass 1930*2000mm |
set |
3 |
| window |
Aluminum alloy sliding window 1100*930/rotating ear, double layer tempered glass wall 1 side |
set |
5 |
| ground |
15mm modified floor, 15mm plastic wood floor |
㎡ |
38 |
| Corner Line |
WPC Decoration Line |
set |
1 |
| outer wall |
16mm Metal Insulation Carved Panel, Decorative Hanging Panel for Exterior Wall |
set |
1 |
| Electrical system |
Industrial waterproof socket (including plug) |
set |
1 |
| Distribution Box |
set |
1 |
| Circuit breakers, protectors |
set |
1 |
| American standard special socket |
set |
4 |
| US Standard Cable |
meter |
120 |
| LED ceiling light |
Personal |
4 |
| seal |
Sealing tape, aluminum foil butyl adhesive |
meter |
380 |
| accessories |
Screws etc. |
set |
1 |
| accessories |
793 Structural adhesives, 995 Silicone weather-resistant adhesives, transparent glass adhesives |
set |
1 |
| Cabinet (additional charge) |
L-shaped countertops, terrazzo countertops (including basins, hardware, stainless steel parts), drain area |
set |
1 |
| Bathroom |
800 fan-shaped tempered glass shower with shower head, straight toilet bowl, floor drain, vanity mirror, ceramic washstand, wall cabinet, ventilation fan, |
set |
1 |
| Intake and drainage system |
PPR25 water supply pipe (cold water, hot water pipe), quick connector, sewer pipe (PVC110 stool), PVC50 pipe, vegetable washing sewer pipe, wrapped with insulation and antifreeze cotton |
set |
1 |
|
